1-1564536-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
9 mm[.354 in]
Product Description:
4pos,tab5.8x0.8,tabhsg,assy,sld

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector No
Number of holes 4
Number of rows 1
Body material PBT GF
Outlet angle 180°
Main Product Colour Black
Centreline (pitch) 9 mm[.354 in]
Product Height 39.8 mm [1.56 in]
Product length 62.5 mm
Product Width 50.6 mm[1.99 in]
UL Flame Retardant Rating UL 94V-0
Packaging Box
Packaging Quantity 150
Width at male end 5.8 mm[.228 in]
Circuit Application Signal
Waterproof Rating IP67
Operating Voltage 60 VDC
Nominal Voltage Architecture 12 V, 24 V, 42 V, 60 V
Connectors and terminals terminated to -
Terminal current rating (max)
