1-2208685-6

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
5 mm[.197 in]
Product Description:
31pos, mixed,rec hsg,assy

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector Yes
Number of holes 31
Number of rows 2,3
Body material PBT GF
Outlet angle 90°
Main product colour Other
Centreline (pitch) 5 mm[.197 in]
Product height 44 mm [1.732 in]
Product length 120.5 mm
Product width 46 mm [1.811 in].
UL Flame retardancy class UL 94V-0
Packaging method
Packaging Quantity
Width at male end of butt joint 2.8 mm [.11 in]
Circuit Application Power and Signal
Waterproof Rating IP67,IP69K
Operating Voltage 36 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
