1-2208686-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
5 mm[.197 in]
Product Description:
21POS,AMP MCP2.8,REC HSG,ASSY

Connector Type Female
Connector System Wire to Wire, Wire to Board
Waterproof Yes
Hybrid connector No
Number of holes 21
Number of rows 3
Body material PBT GF
Outlet angle 90°
Main Product Colour Black
Centreline (pitch) 5 mm[.197 in]
Product Height 37.9 mm [1.492 in]
Product length 69.2 mm
Product Width 43.7 mm [1.72 in].
UL Flame retardancy rating UL 94V-0
Packaging method
Packaging Quantity
Butt Male Width 2.8 mm[.11 in]
Circuit Application Signal
Waterproof Rating IP67,IP6K9K
Operating Voltage 28 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal current rating (max.)
