1-2236954-5

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
4 mm[.157 in]
Product Description:
5POS, MCON 1.2 LL TAB SEALED COD A

Connector Type Male
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 5
Number of rows 1
Body material PA GF
Outlet angle 180°
Main Product Colour Black
Centreline (pitch) 4 mm[.157 in]
Product Height 16.3 mm[.642 in]
Product length 28.2 mm
Product Width 44 mm [.732 in] Product Height 16.3 mm [.642 in] Product Length 28.2 mm
UL Flame Retardant Rating No
Packaging Method
Packaging Quantity
Butt Male Width 1.2 mm [.047 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 14 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
