1-2294256-5

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
4 mm[.157 in]
Product Description:
4POS, MCON 1.2 LL REC SEALED

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 4
Number of rows 1
Body material PA
Outlet angle -
Main Product Colour Black
Centreline (Pitch) 4 mm [.157 in]
Product Height 16.5 mm[.649 in]
Product Length 24.7 mm
Product Width 26.5 mm[.1.04 in]
UL Flame Retardant Rating -
Packaging method
Package Quantity -
Butt Male Width 1.51 mm[.059 in]
Circuit Application Power Supply
Water Resistance Rating - - Water Resistant - - Waterproof
Operating Voltage
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to wires and cables
Terminal Current Ratings (Max)
