1-2294803-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
3.85 mm[.15 in]
Product Description:
96pos,mcon 1.2 cb,rec hsg,assy

Connector Type Female
Connector System Board to Board
Waterproof Yes
Hybrid Connector Yes
Number of holes 96
Number of rows 4
Body Material -
Outlet angle 90°
Main Product Colour Black
Centreline (pitch) 3.85 mm[.15 in]
Product Height 35.71 mm [1.41 in]
Product Length 82.3 mm
Product width 42 mm[1.65 in] Product height 35.71 mm[1.41 in] Product length 82.3 mm
UL Flame Retardant Rating No
Packaging method Box
Packaging Quantity 148
Mating Male Width 2.8 mm[.11 in]
Circuit Application Power and Signal
Waterproof Rating IPX4,IPX5,IPX7,IPX9K
Operating Voltage - Nominal
Nominal Voltage Architecture -
Connectors and terminals terminated to -
Terminal current rating (max) 22 A
