1-2301521-5

Type: Automotive Connector Boot

Brand: TE

Connectivity Colour: 4 mm

Description: 10POS, MCON 1.2 LL TAB SEALED 2ROW

Connector type Male

Connector system Wire to wire

Waterproof Yes

Hybrid connector No

Number of holes 10

Number of rows 2

Body material PA GF,PBT GF

Outlet angle 180°

Main product colours Black

Centre line (pitch) 4 mm

Product height 16.2 mm

Product length 29.3 mm

Product width 48 mm

UL Flame retardancy rating -

Packaging method -

Packing quantity -

Mating male width .6 mm

Circuit application Signal

Waterproof rating -

Operating Voltage -

Nominal voltage structure 25 V

Connectors and terminals terminated in wires and cables

Terminal current rating (max.)
