1-2303064-2

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
4.19 mm[.164 in]
Product Description:
12pos,stamped 20,pin hsg assy,sld,cod 2

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 12
Number of rows 2
Body material PA GF
Outlet angle 180
Main Product Color Black
Centerline (Pitch) 4.19 mm[.164 in]
Product Height 35.56 mm [.1.4 in]
Product Length 55.12 mm
Product Width 43.69 mm[1.72 in]
UL Flame Retardant Rating No
Packaging method Box
Packaging Quantity 180
Butt Male Width -
Circuit Application Power and Signal
Waterproof Rating -
Operating Voltage 12 VDC
Nominal Voltage Architecture
Connectors and terminals terminated to wire and cable
Terminal Current Rating (Max) 7.5 A
