1-284425-3

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
4 mm[.157 in]
Product Description:
3 POS CONNECTOR FOR INJECTION

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 3
Number of rows 1
Body material PBT GF
Outlet angle 180°
Main Product Color Gray
Centerline (pitch) 4 mm[.157 in]
Product Height 22.6 mm [.89 in]
Product length 35.5 mm
Product Width 26.25 mm[.03 in]
UL Flame Retardant Rating No
Packaging method Bag
Packaging Quantity 100
Width at male end 1.5 mm[.059 in]
Circuit Application Signal
Waterproof Rating IP54K
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal current rating (max.)
