1-953600-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
5 mm[.197 in]
Product Description:
5/4w mcp rcpt hsg assy

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 5
Number of rows 1
Body material PBT
Outlet angle 180°
Main Product Color Orange
Centerline (pitch) 5 mm [.197 in]
Product Height 20.1 mm[.791 in]
Product Length 36.8 mm
Product Width 29.7 mm [.1.169 in]
UL Flame Retardant Rating UL 94HB
Packaging Box
Packaging Quantity 500
Width at male end 2.8 mm[.11 in]
Circuit Application Signal
Waterproof Rating IP67
Operating Voltage 16 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
