1452324-3

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
5.5 mm[.217 in]
Product Description:
TAB HOUSING 2.8MM, 4+6POS SEALED

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector No
Number of holes 10
Number of rows 2
Body material PBT GF
Outlet angle 180°
Main Product Colour Black
Centreline (pitch) 5.5 mm[.217 in]
Product Height 47.3 mm [1.862 in]
Product length 24 mm
Product width 30.45 mm [1.199 in].
UL Flame Retardant Rating UL 94HB
Packaging method
Packaging Quantity
Butt Male Width 2.8 mm[.11 in]
Circuit Application Signal
Water Resistance Rating - -
Operating Voltage 14 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
