174516-6

Type:
Automotive Connector Housing
Brand:
AMP
Color:
3 mm[.118 in]
Product Description:
HYBRID I/O CONN PLUG HSG 26P

Connector Type Female
Connector System Wire-to-Board
Waterproof No
Hybrid Connector Yes
Number of Cavities 26
Number of Rows 2
Body Material PBT
Wire Exit Angle 180°
Primary Product Color Gray
Centerline (Pitch) 3 mm[.118 in]
Product Height 30.4 mm[1.197 in]
Product Length 21 mm
Product Width 43.1 mm[1.697 in]
UL Flammability Rating UL 94HB
Packing Method -
Package Quantity 50
Mating Tab Width 1 mm[.04 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 12 VDC
Nominal Voltage Architecture 12 V
Connector and Contacts Terminate to -
Contact Current Rating (Maximum) -
