2-1564536-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
9 mm[.354 in]
Product Description:
4POS,TAB5.8X0.8,TABHSG,ASSY, COD. B

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector No
Number of holes 4
Number of rows 1
Body material PBT GF
Outlet angle 180°
Main Product Color Gray
Centerline (Pitch) 9 mm[.354 in]
Product Height 39.8 mm [.1.56 in]
Product length 62.5 mm
Product Width 50.6 mm [1.99 in].
UL Flame Retardant Rating UL 94V-0
Packaging Method Box
Packaging Quantity
Butt Male Width 5.8 mm[.228 in]
Circuit Application Signal
Waterproof Rating IP67
Operating Voltage 60 VDC
Nominal Voltage Architecture 12 V, 24 V, 42 V, 60 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
