2-2112780-6

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
3.5 mm[.137 in]
Product Description:
18pos, mixed,rec hsg,assy,sealed

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector Yes
Number of holes 18
Number of rows 2
Body material PBT GF
Outlet angle 90°
Main Product Colour Black
Centreline (pitch) 3.5 mm[.137 in]
Product Height 24 mm[.944 in]
Product length 60.3 mm
Product Width 37.1 mm [.1.46 in] Product Height 24 mm [.944 in] Product Length 60.3 mm
UL Flame Retardant Rating No
Packaging Method Box
Packaging Quantity 320
Width at male end 1.2 mm[.047 in]
Circuit Application Signal
Waterproof Rating IPX9K
Operating Voltage 50 VDC
Nominal Voltage Architecture 12 V,24 V,42 V,48 V,50 V
Connectors and terminals terminated to -
Terminal current rating (maximum) -
