2-2303816-3

Type: Automotive Connector Boot

Brand: TE Connectivity

Colour: 10.01 mm[.394 in]

Description: DT06-3S-TN82, PLG, 3P, BLK, N, SNAPXCAP

Connector Type Female

Connector System Wire-to-wire

Watertight Yes

Hybrid Connector No

Number of Holes 3 Rows -

Body Material PA GF

Outlet Angle 180°

Primary Product Colour Black

Centre Line (Pitch) 10.01 mm[.394 in]

Product Height 23.89 mm[.94 in]

Product Length 41.94 mm

Product Width 20.17 mm[.794 in]

ULFlame Retardant Rating 12mm Flame Test per Standard UL-94

Packaging Method Box

Packaging Quantity 900

Mating Male Width -

Circuit Applications Power and Signal

Waterproofing Rating IP68,IP6K9K

Operating Voltage 250 VDC

Nominal Voltage Architecture 12 V,24 V,48 V

Connector and Terminal Termination to Wire andCables

Terminal current rating (max.) 13 A
