2103628-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
10.4 mm[.409 in]
Product Description:
plug assy,1 stage,key a,hva280-2phi se

Connector Type Male
Connector System
Waterproof Yes
Hybrid connector yes
Number of holes 2
Number of rows -
Body material PA GF
Outlet angle 180°
Main Product Colour Orange
Centreline (Pitch) 10.4 mm [.409 in]
Product Height 28.6 mm [.1.12 in]
Product Length 52.7 mm
Product Width 32.9 mm[1.29 in]
UL Flame Retardant Rating -
Packaging Box
Packaging Quantity 50
Width at male end 2.8 mm[.11 in]
Circuit Application Signal
Water Resistance Rating -
Operating Voltage 600 VDC
Nominal Voltage Architecture 12 V,24 V,42 V,48 V,80 V,90 V,125 V,240 V,500 V,550 V,600 V
Connectors and terminals terminated to
Terminal current rating (max.)
