2203804-1
Publish Time: Author: Site Editor Visit: 128
2203804-1
Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
4 mm[.157 in]
Product Description:
PLUG ASS'Y, 2P SEALED, KEY A, CPA
Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 2
Number of rows 1
Body material PBT
Outlet angle 180°
Main Product Colour Black
Centreline (pitch) 4 mm[.157 in]
Product Height 18.05 mm[.71 in]
Product length 15.4 mm
Product width 26.5 mm [.1.04 in]
UL Flame Retardant Rating No
Package
Package Quantity 1
Width at male end 1.2 mm[.047 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage
Nominal Voltage Architecture -
Connectors and terminals terminated to wires and cables
Terminal Current Ratings (Max)
