2209545-9

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.5 mm[.098 in]
Product Description:
94P PLUG ASSY, NORMAL CODING

Connector Type Female
Connector System Wire to Board
Waterproof No
Hybrid connector yes
Number of holes 94
Number of rows 4
Body Material PBT GF
Outlet angle Other
Main Product Colour Black
Centreline (pitch) 2.5 mm[.098 in]
Product Height 29 mm [1.142 in]
Product Length 85.25 mm
Product Width 43 mm[1.692 in] Product Height 29 mm[1.142 in] Product Length 85.25 mm
UL Flame Retardant Rating UL 94V-2
Packaging Box
Packaging Quantity 1
Mating Male Width .64 mm [.025 in]
Circuit Application Signal
Waterproof Rating IPX9K
Operating Voltage - Nominal
Nominal Voltage Architecture -
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
