2236269-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
-
Product Description:
24pos, mixed,rec hsg,20genymcp,assy,coda

Connector Type Female
Connector System Wire to Board
Waterproof No
Hybrid connector yes
Number of holes 24
Number of rows 2
Body material PA GF
Outlet angle -
Main Product Colour Black
Centre line (pitch) -
Product height 20.55 mm
Product Length 31.25 mm
Product width 40.86 mm
UL Flame Retardant Rating No
Packaging method Tray
Packaging Quantity 294
Mating male width .64 mm, 2.8 mm
Circuit Application Power and Signal
Waterproof Rating -
Operating Voltage
Nominal Voltage Rating - - Nominal Voltage Rating - - Nominal Voltage Rating - Nominal Voltage Rating
Connectors and terminals terminated to wire and cable
Terminal Current Ratings (Max)
