2272975-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.54 mm[.1 in]
Product Description:
6 Pos. Sealed MCON 1.2 Connect

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 6
Number of rows 1
Body material PA GF
Outlet angle 90°
Main Product Colour Black
Centreline (pitch) 2.54 mm[.1 in]
Product Height 32.65 mm[1.285 in]
Product Length 24.5 mm
Product Width 18.3 mm[.72 in]
UL Flame Retardant Rating UL 94HB
Packaging Method Bag/Box
Package Quantity
Butt Male Width 1.2 mm[.047 in]
Circuit Application Signal
Waterproof Rating IP67
Operating Voltage - Nominal
Nominal Voltage Architecture -
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
