2286003-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
4.5 mm[.175 in]
Product Description:
dt06-2s-sdt-ce27-2pos,ce,soc.hsg

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 2
Number of rows 1
Body material Other
Outlet angle 180°
Main Product Colour Earth Yellow
Centreline (pitch) 4.5 mm[.175 in]
Product Height 11.6 mm[.457 in]
Product Length 19.2 mm
Product width 14.9 mm [.586 in].
UL Flame Retardant Rating UL 94V-0
Packaging Method Box & Carton
Packaging Quantity
Butt Male Width -
Circuit Application
Waterproof Rating IP66
Operating Voltage 48 VDC
Nominal Voltage Architecture 12 V, 24 V, 42 V, 48 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
