2286003-3

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
4.5 mm[.175 in]
Product Description:
2POS. DT. REC HSG. ASSY. SEALED

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 2
Number of rows 1
Body material Other
Outlet angle 180°
Main Product Colour Earth Yellow
Centreline (pitch) 4.5 mm[.175 in]
Product Height 15.8 mm[.622 in]
Product Length 31.6 mm
Product Width 15 mm [.591 in].
UL Flame Retardant Rating UL 94V-0
Packaging Method
Packaging Quantity
Width at male end -
Circuit Application
Waterproof Rating IP67
Operating Voltage 48 VDC
Nominal Voltage Architecture 12 V, 24 V, 42 V, 48 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
