2287450-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.2 mm[.087 in]
Product Description:
56pos,miced,tab hsg,025,090, code a,assy

Connector Type Male
Connector System Wire to Wire
Waterproof No
Hybrid connector yes
Number of holes 56
Number of rows 4,6
Body material PBT
Outlet angle 180
Main Product Colour Earth Yellow
Centreline (pitch) 2.2 mm [.087 in]
Product Height 33 mm [.1.29 in]
Product length 43 mm
Product Width 40.5 mm [1.59 in].
UL Flame Retardant Rating -
Packaging method Boxes and trays
Packaging Quantity 240
Butt Male Width .64 mm[.025 in]
Circuit Application Signal
Water Resistance Rating -
Operating Voltage -
Nominal Voltage Rating - Operating Voltage -
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
