2287871-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.2 mm[.087 in]
Product Description:
24pos,miced,tab hsg,025,090, code a,assy

Connector Type Male
Connector System Wire to Wire
Waterproof No
Hybrid connector yes
Number of holes 24
Number of rows 2,3
Body material PBT
Outlet angle 180
Main Product Colour Earth Yellow
Centreline (pitch) 2.2 mm[.087 in]
Product Height 26.65 mm [.1.05 in]
Product length 40.2 mm
Product Width 39.5 mm [1.55 in]
UL Flame Retardant Rating -
Packaging method Boxes and trays
Packaging Quantity 240
Butt Male Width .64 mm[.025 in]
Circuit Application Signal
Water Resistance Rating -
Operating Voltage -
Nominal Voltage Rating - Nominal Voltage Architecture - Nominal Voltage - Nominal Voltage
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
