2288276-1

Publish Time: Author: Site Editor Visit: 101

2288276-1

2288276-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.54 mm[.1 in]
Product Description:
Assy,Plug,USCAR,GenY,20p,Key A, No CPA





Connector Type Female
Connector System Wire to Board
Waterproof No
Hybrid connector No
Number of holes 20
Number of rows 2
Body material PA GF
Outlet angle 180°
Main Product Colour Black
Centreline (pitch) 2.54 mm[.1 in]
Product Height 22.05 mm[.868 in]
Product Length 28.7 mm
Product Width 21.4 mm[.843 in]
UL Flame Retardant Rating
Package
Package Quantity 360
Width at male end .64 mm[.025 in]
Circuit Application Signal
Water Resistance Rating -
Nominal Voltage
Nominal Voltage Rating - Operating Voltage - Nominal Voltage Architecture - Nominal Voltage
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
