2294489-1

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
-
Product Description:
hdp24-18-6pn-l024, rec, 6p, n,thd,4/16,p

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector yes
Number of holes 6
Number of rows -
Body material PA GF
Outlet angle 180°
Main product colour black
Centreline (pitch) -
Product Height 41.28 mm [1.625 in]
Product length 41.53 mm
Product Width 44.45 mm [1.75 in] - Product Height 41.28 mm [1.625 in
UL Flame rating 20 mm flame test per UL-94 standard
Packaging Box
Packaging Quantity 200
Butt Male Width -
Circuit Application Power and Signal
Waterproof rating IP67
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V, 48 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 13 A,100 A
