2294490-1

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
-
Product Description:
hdp26-18-6sn-l024, plg, 6p,n,wthd,4/16,s

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector Yes
Number of Holes 6
Number of rows -
Body material PA GF
Outlet angle 180°
Main product colour black
Centreline (pitch) -
Product Height 43.17 mm [1.7 in]
Product length 38.3 mm
Product Width 43.17 mm [1.7 in] - Product Height 43.17 mm [1.7 in] - Product Length 38.3 mm
UL Flame rating 20 mm flame test per UL-94 standard
Packaging Box
Packaging Quantity 200
Width at male ends - - Circuit applications
Circuit Applications Power and Signal
Waterproof rating IP67
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V, 48 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 13 A,100 A
