2295167-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.6 mm[.102 in]
Product Description:
22pos,0.64 male gen. y,tabhsg,assy,sld

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector Yes
Number of holes 22
Number of rows -
Body material PBT GF
Outlet angle 180°
Main Product Colour Black
Centreline (Pitch) 2.6 mm[.102 in]
Product Height 28 mm [1.12 in]
Product length 37 mm
Product width 42.02 mm [1.65 in].
UL Flame Retardant Rating No
Packaging method
Packaging Quantity
Butt Male Width .64 mm[.025 in]
Circuit Application Signal
Water Resistance Rating - -
Operating Voltage
Nominal Voltage Rating - Nominal Voltage Frame - Nominal Voltage Frame - Nominal Voltage Frame
Connectors and terminals terminated to -
Terminal Current Ratings (Max)
