2298173-1

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
9.12 mm[.359 in]
Product Description:
dt04-08pa-p089, rec, 8p gry,busbar,3x2,a

Connector Type Male
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 8
Number of rows 2
Body material PA GF
Outlet angle 180
Main product colour Grey
Centreline (Pitch) 9.12 mm[.359 in]
Product Height 23.88 mm[.94 in]
Product Length 46.94 mm
Product Width 36.45 mm [1.435 in]
UL Flame Retardant Rating 12mm Flame Test per Standard UL-94
Packaging Box
Packaging Quantity 300
Width at male end -
Circuit Application Power and Signal
Waterproof Rating IP68,IP6K9K
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V, 48 V
Connectors and terminals terminated to bus bars, wires and cables
Terminal current rating (max) 13 A
