2299123-1

Type: Automotive Connector Sheath

Brand: TE

Connectivity Color: -

Product Description: 1POS,P2P,SOC HSG ASSY,180DEG,CODA,UL94V0

Connector Type Female

Connector System

Waterproof Yes

Hybrid Connector Yes

No. of Holes 1

No. of Rows 1

Body Material PA

Outlet Angle 180°

Primary Product Colour Orange

Centre Line (Pitch) -

Product Height 60.4 mm [2.378 in]

Product Length 93 mm

Product Width 56.8 mm [2.236 in]

UL Flame Retardant Rating UL 94V-0

Packaging Method Box

Packing Quantity-

Mating Male Width -

Circuit Applications Power and Signal

Waterproofing IP2XB

Operating Voltage 650 VDC

Nominal Voltage Architecture 650 V

Connectors and Terminals Terminated to Wires and Cables

Terminal Current Rating (Max) 200 A
