2303454-1

Type： Automotive Connector Boot

Brand： DEUTSCH

Colour： 9.12 mm[.359 in]

Description： DT04-6P-LE14, REC, 6P, BLK, N, FLANGE

Connector Type Male

Connector System Wire-to-wire

Waterproof Yes

Hybrid connector No

No. of holes 6

No. of rows 3

Body Material PA GF

Outlet Angle 180°

Primary Product Colour Black

Centre Line (Pitch) 9.12 mm[.359 in]

Product Height 54.99 mm[2.165 in]

Product Length 45.92 mm

Product Width 35.51 mm[1.398 in]

ULFlame Retardant Rating 12mm Flame Test per Standard UL-94

Packaging Method Box

Packaging Quantity 400

Mating Male Width -

Circuit Applications Power and Signal

Waterproofing Rating IP68,IP6K9K

Operating Voltage 250 VDC

Nominal Voltage Architecture 12 V,24 V,48 V

Connector and Terminal Termination to Wire andCables

Terminal current rating (max.) 13 A
