2323768-3

Type:
Automotive connector sheath
Brand:
DEUTSCH
Color:
9.12 mm[.359 in]
Product Description:
dt04-12pc-ce04, rec, 12p, grn, xcap, c

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 12
Number of rows 2
Body material PA GF
Outlet angle 180°
Main Product Color Green
Centerline (pitch) 9.12 mm[.359 in]
Product Height 22.25 mm [.876 in]
Product Length 56.29 mm
Product Width 40.56 mm [.1.597 in]
UL Flame Rating 12mm Flame Test per Standard UL-94
Packaging Method Box
Packaging Quantity 250
Butt Male Width -
Circuit Application Power and Signal
Waterproof Rating IP68,IP6K9K
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V, 48 V
Connectors and terminals terminated to wire and cable
Terminal current rating (max.) 13 A
