2324808-3

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
5 mm[.197 in]
Product Description:
2POS,MCON 1.2,REC HSG ASSY,SLD,COD C

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 2
Number of rows 1
Body material PBT GF
Outlet angle 180°
Main Product Color Black
Centerline (Pitch) 5 mm[.197 in]
Product Height 15.77 mm[.621 in]
Product Length 33.17 mm
Product Width 16.48 mm[.649 in]
UL Flame Retardant Rating UL 94V-0
Packaging Method Box
Packaging Quantity 1200
Width at male end 1.2 mm[.047 in]
Circuit Application Signal
Waterproof Rating IP67,IP69K
Operating Voltage 12 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 7.5 A,14 A
