2337311-1

Type:
Automotive connector sheath
Brand:
AMP
Color:
5 mm[.197 in]
Product Description:
2x2 plg asy key h c3 w/cpa

Connector Type Female
Connector System Wire to Wire, Wire to Board
Waterproof Yes
Hybrid connector No
Number of holes 4
Number of rows 2
Body material PBT GF
Outlet angle 180°
Main Product Color Black
Centerline (Pitch) 5 mm[.197 in]
Product Height 27.6 mm [1.09 in]
Product length 30.6 mm
Product Width 23.2 mm[.913 in]
UL Flame Retardant Rating UL 94HB
Package
Package Quantity 1000
Width at Male Connector
Circuit Application
Waterproof Rating
Operating Voltage 125 VDC
Nominal Voltage Architecture 12 V, 24 V, 42 V, 48 V, 80 V, 90 V, 125 V
Connector and Terminal Termination to -
Terminal Current Ratings (Max)
