2338360-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
4.8 mm[.189 in]
Product Description:
2P ECONOSEAL RECEPTACLE ASSY

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector No
Number of holes 2
Number of rows 1
Body material PBT
Outlet angle 180°
Main Product Color Black
Centerline (pitch) 4.8 mm[.189 in]
Product Height 22.8 mm[.883 in]
Product Length 27.6 mm
Product Width 20.68 mm[.814 in]
UL Flame Retardant Rating UL 94HB
Packaging Method Box
Packaging Quantity 1200
Width at male end 1.8 mm[.071 in]
Circuit Application Power Supply
Waterproof rating IP67
Operating Voltage 12 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal current rating (max) 10 A
