2358801-2

Type:
Automotive connector sheath
Brand:
TE Connectivity
Color:
4 mm[.157 in]
Product Description:
62POS,2.8X0.8,TAB HSG ASSY,SLD,COD B

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector yes
Number of holes 62
Number of rows 3
Body material PBT GF
Outlet angle 90°
Primary Product Color Black
Centerline (Pitch) 4 mm[.157 in]
Product Height 45.8 mm [1.803 in]
Product length 113.25 mm
Product Width 70.7 mm [2.783 in]
UL Flame Retardant Rating UL 94HB
Packaging Box
Packaging Quantity 80
Width at male end 1.5 mm[.059 in]
Circuit Application Signal
Waterproof Rating IP67,IP69K
Operating Voltage 36 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal current rating (max.)
