284073-1

Type:
Automotive Connector Housing
Brand:
TE Connectivity
Color:
6 mm[.236 in]
Product Description:
AMP SUPERSEAL 1.5 SERIES 3P PL

Connector Type Receptacle
Connector System Wire-to-Wire
Waterproof Yes
Hybrid Connector No
Number of Cavities 3
Number of Rows 1
Body Material PA GF
Wire Exit Angle 180°
Primary Product Color Black
Center Line (Pitch) 6 mm [.236 in]
Product Height 32.2 mm [1.268 in]
Product Length 23.1 mm
Product Width 9.3 mm [.366 in]
UL Flammability Rating No
Packing Method Bag
Package Quantity 650
Mating Tab Width 1.5 mm [.059 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connector and Contacts Terminate to -
Contact Current Rating (Maximum) -
