284858-4

Type:
Automotive Connector Housing
Brand:
AMP
Color:
4.2 mm[.165 in]
Product Description:
12 POS MALE HOUSING ASS'Y

Connector Type Male
Connector System Wire-to-Wire
Waterproof No
Hybrid Connector No
Number of Cavities 12
Number of Rows 2
Body Material PA GF
Wire Exit Angle 180°
Primary Product Color Gray
Center Line (Pitch) 4.2 mm [.165 in]
Product Height 38.7 mm [1.524 in]
Product Length 34.3 mm
Product Width 20.8 mm [.819 in]
UL Flammability Rating No
Packing Method Box
Package Quantity 900
Mating Tab Width 1.6 mm [.063 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connector and Contacts Terminate to -
Contact Current Rating (Maximum) -
