3-1534903-1

Type:
Automotive connector sheath
Brand:
AMP
Color:
2.5 mm[.098 in]
Product Description:
CONNECTOR HSG 60 POS.

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 60
Number of rows 4
Body material PBT GF
Outlet angle -
Main Product Color Black
Centerline (pitch) 2.5 mm [.098 in]
Product Height 43 mm [.1.693 in]
Product Length 60.65 mm
Product Width 36.5 mm [1.437 in]
UL Flame Retardant Rating UL 94HB
Packaging Method Box
Packaging Quantity
.63 mm [.025 in] Width at Male Connection
Circuit Application Signal
Waterproof Rating
Operating Voltage 12 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
