3-2308295-1

Type:Automotive connector sheath
Brand:TE Connectivity
Color:-
Product Description:1pos,pcon12,rec hsg,90 deg,unsld,cod c

Connector Type Female
Connector System Wire to Board
Waterproof No
Hybrid Connector No
Number of holes 1
Number of rows
Body material PBT GF
Outlet angle 90°
Main product color Black
Centerline (Spacing) -
Product Height 19.5 mm [.767 in]
Product Length 45 mm
Product Width 24.9 mm[.978 in]
UL Flame Retardant Rating UL 94V-0
Packaging Method Box
Packaging Quantity
Width at male end 9.5 mm[.374 in]
Circuit Application Power Supply
Waterproof rating IP20
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 60 A
