3-969508-2

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.54 mm[.1 in]
Product Description:
6POS MQS REC COD C

Connector Type Female
Connector System Wire to Wire, Wire to Board
Waterproof No
Hybrid connector No
Number of holes 6
Number of rows 1
Body material PBT GF
Outlet angle 180
Main product colour blue
Centreline (pitch) 2.54 mm[.1 in]
Product Height 10.6 mm[.417 in]
Product Length 17.7 mm
Product Width 16 mm[.63 in]
UL Flame Retardant Rating No
Packaging Carton
Package Quantity 500
Mating Male Width .63 mm [.025 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to wires and cables
Terminal Current Rating (Max)
