4-2299782-1

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
6 mm,9 mm
Product Description:
8pos,miced,rec hsg,assy,sld

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector Yes
Number of holes 8
Number of rows 1,2
Body material PBT GF
Outlet angle 180°, 90
Main product colour blue
Centre line (pitch) 6 mm,9 mm
Product height 31.25 mm
Length 67.2 mm
Product width 25.7 mm
UL Flame retardant rating UL 94V-0
Packaging method Box
Packaging Quantity
Width at male end 2.8 mm,6.3 mm
Circuit Application Power and Signal
Waterproof rating IP67,IP69K
Operating Voltage 60 VDC
Nominal Voltage Architecture
Connectors and terminals terminated to wire and cable
Terminal Current Ratings (Max)
