4-284272-6

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.5 mm[.098 in]
Product Description:
64 pos female hsg. bosch motor side

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector No
Number of holes 64
Number of rows 4
Body material PA GF
Outlet angle 90°
Main product colour Other
Centreline (pitch) 2.5 mm[.098 in]
Product Height 35.3 mm [.1.389 in]
Product length 38.5 mm
Product Width 88.8 mm[3.496 in]
UL Flame Retardant Rating No
Packaging method Box
Package Quantity 155
Mating Male Width .63 mm[.025 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 24 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal Current Rating (max)
