6-2208684-3

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
5 mm[.197 in]
Product Description:
39POS,AMP MCP2.8,REC HSG,ASSY

Connector Type Female
Connector System Wire to Wire, Wire to Board
Waterproof Yes
Hybrid connector No
Number of holes 39
Number of rows 3
Body material PBT GF
Outlet angle 90°
Main product colour Brown
Centreline (Pitch) 5 mm [.197 in]
Product height 44 mm [1.732 in]
Product length 120.5 mm
Product width 46 mm [1.811 in].
UL Flame Retardant Rating UL 94V-0
Packaging method
Packaging Quantity
Butt Male Width 2.8 mm[.11 in]
Circuit Application Signal
Waterproof Rating IP67,IP69K
Operating Voltage 36 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to -
Terminal current rating (max.)
