8-1564285-8

Type:
Automotive connector sheath
Brand:
TE Connectivity
Colour:
2.5 mm[.098 in]
Product Description:
58pos, mixed,rec hsg,assy

Connector Type Female
Connector System Wire to Board
Waterproof Yes
Hybrid Connector Yes
Number of holes 58
Number of rows 4
Body Material PA GF
Outlet angle Other
Main Product Colour Black
Centreline (pitch) 2.5 mm[.098 in]
Product Height 35.7 mm [1.406 in]
Product Length 61.9 mm
Product Width 42 mm[1.654 in] Product Height 35.7 mm[1.406 in] Product Length 61.9 mm
UL Flame Retardant Rating No
Packaging method
Number of packages -
Butt Male Width 1.2 mm [.047 in]
Circuit Application Signal
Waterproof Rating -
Operating Voltage 14 VDC
Nominal Voltage Architecture 12 V
Connectors and terminals terminated to -
Terminal Current Rating (Max)
