YHD10-9-96PE-BE090

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
-
Product Description:
rec, 9p, gry, e, panel, 16

Connector Type Male
Connector System Wire to Wire
Waterproof Yes
Hybrid connector No
Number of holes 9
Number of rows -
Body material PA GF
Outlet angle 180
Main product colour Grey
Centreline (spacing) -
Product Height 41.28 mm [1.625 in]
Product length 42.18 mm
Product Width 44.45 mm [1.75 in] - Product Height 41.28 mm [1.625 in
UL Flame rating 20 mm flame test according to UL-94 standard
Packaging Method Box
Packaging Quantity 250
Width at male end -
Circuit Application Power and Signal
Waterproof Rating IP68,IP6K9K
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 13 A
