YHD36-24-18SE-0590

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
-
Product Description:
plg, 18p,al,e,cbclclmpbt,drain,8/12/16, s

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector Yes
Number of Holes 18
Number of rows -
Body material aluminium
Outlet angle 180
Main product colour -
Centreline (pitch) -
Product Height 49.32 mm [1.942 in]
Product length 81.05 mm
Product width 49.32 mm [1.942 in] - Product height 49.32 mm [1.942 in] - Product length 81.05 mm
UL Flame Retardant Rating No
Packaging Method Box
Packaging Quantity 80
Width at male end -
Circuit Application Power and Signal
Waterproof rating IP67
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V
Connectors and terminals terminated to wires and cables
Terminal current ratings (max.) 13 A,25 A,60 A
