YHDP26-18-20SEL024

Type:
Automotive connector sheath
Brand:
DEUTSCH
Colour:
-
Product Description:
plg, 20p, blk, e, wthd, 16/20, s

Connector Type Female
Connector System Wire to Wire
Waterproof Yes
Hybrid Connector Yes
Number of holes 20
Number of rows -
Body material PA GF
Outlet angle 180°
Main product colour black
Centreline (pitch) -
Product Height 43.17 mm [1.7 in]
Product length 38.3 mm
Product Width 43.17 mm [1.7 in] - Product Height 43.17 mm [1.7 in] - Product Length 38.3 mm
UL Flame rating 20 mm flame test per UL-94 standard
Packaging Method Box
Packaging Quantity
Width at male end -
Circuit Applications Power and Signal
Waterproof rating IP67
Operating Voltage 250 VDC
Nominal Voltage Architecture 12 V, 24 V, 48 V
Connectors and terminals terminated to wires and cables
Terminal current rating (max.) 7.5 A,13 A
